Biodiesel Production Line

Biodiesel Production Line

Model Biodiesel line

Biodiesel Production Line

Used cooking oil, animal fat and high-acid feedstock converted into biodiesel through pre-treatment, filtration, dehydration, esterification, transesterification, methanol recovery and purification. The line is engineered around the feedstock the plant can actually secure and the fuel specification it has to sell into, rather than a fixed catalogue configuration.

Request a quote

Specification

Catalogue figures

Biodiesel Production Line specification
ParameterValue
FeedstockUsed cooking oil, animal fat and tallow, acid oil and soapstock
Process stagesPre-treatment, filtration, dehydration, esterification, transesterification, methanol recovery, purification
ProductsBiodiesel (FAME) and crude glycerol
Design basisBuilt around the project feedstock, target capacity and product specification
ScopeThe complete line, or individual process stages where part of the plant exists
FeedstockUsed cooking oil, animal fat and tallow, acid oil and soapstock
Process stagesPre-treatment, filtration, dehydration, esterification, transesterification, methanol recovery, purification
ProductsBiodiesel (FAME) and crude glycerol
Design basisBuilt around the project feedstock, target capacity and product specification
ScopeThe complete line, or individual process stages where part of the plant exists

Figures are catalogue values. Final sizing is confirmed against your raw material and required capacity.

Applications

Where it is used

  • Collectors and food waste processors — converting collected waste cooking oil into a saleable fuel
  • Rendering plants — extending fat and tallow recovery into biodiesel
  • Biodiesel plants — pre-treatment, reaction and methanol recovery stages inside an existing line

Process

How the line runs

  1. 01

    Collection and pre-treatment

    Collected oil is received, screened and settled.

  2. 02

    Filtration

    Solids and debris are removed ahead of heating.

  3. 03

    Dehydration

    Water is driven off to the level the reaction tolerates.

  4. 04

    Esterification

    Free fatty acids are converted ahead of transesterification.

  5. 05

    Transesterification

    Triglycerides are converted into methyl esters.

  6. 06

    Glycerol separation

    Crude glycerol is drawn off from the ester phase.

  7. 07

    Methanol recovery

    Excess methanol is recovered and returned to the process.

  8. 08

    Purification

    Finished biodiesel is purified and the glycerol stream handled.

Questions

Common questions

Used cooking oil, animal fat and tallow, acid oil and soapstock. High free fatty acid feedstock needs an esterification stage ahead of transesterification.

Capacity is set by the feedstock volume the plant can secure rather than by a catalogue size. Send us the figure and we will confirm the configuration.

Yes. Pre-treatment, reaction, methanol recovery and purification are supplied as individual stages where part of the process already exists on site.

Against the standard the plant sells into. Tell us which one applies and we will confirm the specification the line is designed to meet.

Yes. Installation and commissioning of the complete project are part of our scope, with technical guidance during start-up.

Quote for Biodiesel Production Line

Send us the raw material and the throughput you are targeting and our engineers will confirm the configuration, scope and delivery.
